SRM T3 EV
YOUR ULTIMATE ELECTRIC WORKHORSE
The SRM T3EV Electric Lorry is a compact and efficient cargo transport solution with dimensions of 5,190 mm in length, 1,770 mm in width, and 1,995 mm in height. It boasts a payload capacity of 1,625 kg and a gross vehicle weight of 3,155 kg, making it suitable for various cargo needs. The vehicle is equipped with a 60 kW Permanent Magnet Synchronous Motor, a CATL LFP Battery with 53.58 kWh capacity, and offers an estimated driving range of 310 km.
The lorry supports both AC and DC charging standards, with charging times ranging from 3 hours (AC) to 48 minutes (DC) for a 20-80% charge. It features a rear motor with rear-wheel drive, McPherson independent suspension at the front, and a 6-leaf spring top-mount suspension at the rear. The braking system includes disc brakes at the front and drum brakes at the rear.
Safety features include ABS + EBD, airbags, and EPS (Auto Return). The vehicle rolls on 195/70R15LT tires. Overall, the SRM T3EV combines practical dimensions, efficient performance, and eco-friendly features for a reliable and sustainable cargo transportation solution.
- There are no features available
| Category | Specification |
|---|---|
| Vehicle Dimensions | |
| Length | 5,190 mm |
| Width | 1,770 mm |
| Height | 1,995 mm |
| Vehicle Dimensions & Weights | |
| Wheelbase | 3,400 mm |
| Unladen Weight | 1,530 kg |
| Gross Vehicle Weight | 3,155 kg |
| Payload | 1,625 kg |
| Seating Capacity | 2 |
| Deck Length | 3,100 mm |
| Cargo Area Dimensions | |
| Deck Width | 1,680 mm |
| Deck Height | 370 mm |
| Powertrain | |
| Max Power | 60 kW (80 bhp) |
| Torque | 220 Nm |
| Battery Type | CATL LFP Battery |
| Battery Capacity | 53.58 kWh |
| Driving Range (WLTP) | Combined: 310 km (estimated) |
| AC Input (kW) | 11 kW |
| DC Input (kW) | 40 kW |
| Charging Standard | AC-Type 2 |
| Motor Details | |
| Motor Type | Permanent Magnet Synchronous Motor |
| Motor Model | TZ180XS000 |
| Number of Gears | 3 (D/N/R) |
| Charging Time (20-80%) | AC: 3 hrs / DC: 48 mins |
| Drive System | Rear Motor, Rear-wheel drive (RWD) |
| Suspension | |
| Front | McPherson independent suspension |
| Rear | 6 Leaf spring top-mount suspension |
| Brake | |
| Front | Disc |
| Rear | Drum |
| Chassis | |
| Brake | ABS + EBD |
| Airbags | Yes |
| EPS (Auto Return) | Yes |
| Tires | 195/70R15LT |
Fuel Efficiency Rating
- City: N/A
- Highway: N/A
Actual rating will vary with options, driving conditions, driving habits and vehicle condition.
